Build a URL Shortener: Deployment & Production

We've built a full-stack URL shortener — API, database, cache, auth, frontend, and tests. It all works beautifully on your laptop. But software that only runs on localhost isn't software — it's a prototype.

This final post takes our project from development to production. We'll containerize everything with Docker, automate deployments with GitHub Actions, add monitoring with Prometheus and Grafana, and harden the application for real-world traffic.

Time commitment: 2–3 hours
Prerequisites: Phase 8: Testing Strategy

What we'll build in this post:
✅ Multi-stage Docker builds for API and frontend
✅ Docker Compose orchestrating the full stack
✅ GitHub Actions CI/CD pipeline (lint, test, build, deploy)
✅ Detailed health check endpoints with dependency status
✅ Prometheus metrics and Grafana dashboards
✅ Structured JSON logging with pino
✅ Production hardening (Helmet, CORS, compression)
✅ Nginx reverse proxy configuration

Production Architecture Overview

Here's what our production deployment looks like:

Every component runs in its own Docker container. Let's build it layer by layer.

Multi-Stage Docker Build: API Server

Multi-stage builds keep production images small by separating the build environment from the runtime environment.

API Dockerfile

# Dockerfile (API)

# ── Stage 1: Build ──────────────────────────────
FROM node:20-alpine AS builder

WORKDIR /app

# Copy dependency files first (layer caching)
COPY package.json package-lock.json ./
COPY prisma ./prisma/

# Install all dependencies (including devDependencies for building)
RUN npm ci

# Generate Prisma client
RUN npx prisma generate

# Copy source code
COPY tsconfig.json ./
COPY src ./src/

# Build TypeScript
RUN npm run build

# ── Stage 2: Production ────────────────────────
FROM node:20-alpine AS production

WORKDIR /app

# Create non-root user for security
RUN addgroup -g 1001 -S appgroup && \
    adduser -S appuser -u 1001 -G appgroup

# Copy dependency files
COPY package.json package-lock.json ./
COPY prisma ./prisma/

# Install production dependencies only
RUN npm ci --only=production && \
    npx prisma generate && \
    npm cache clean --force

# Copy built files from builder stage
COPY --from=builder /app/dist ./dist

# Set ownership
RUN chown -R appuser:appgroup /app

USER appuser

# Expose port
EXPOSE 3000

# Health check
HEALTHCHECK --interval=30s --timeout=5s --start-period=10s --retries=3 \
  CMD wget --no-verbose --tries=1 --spider http://localhost:3000/health || exit 1

# Start the server
CMD ["node", "dist/index.js"]

Why multi-stage?

The builder stage has TypeScript compiler, dev dependencies — ~400MB
The production stage has only runtime code — ~150MB
That's a 60% reduction in image size

Why non-root user? If an attacker exploits a vulnerability in our app, they get limited access instead of root privileges inside the container.

Why npm ci instead of npm install? npm ci installs from lock file exactly, ensuring reproducible builds. It also deletes node_modules first, preventing stale dependencies.

.dockerignore

# .dockerignore
node_modules
dist
.env
.env.local
.git
.gitignore
*.md
tests
coverage
.vscode
docker-compose*.yml

This prevents copying unnecessary files into the Docker build context, speeding up builds significantly.

Docker Build: Frontend

The React frontend gets its own Docker image, served by Nginx for production performance.

# frontend/Dockerfile

# ── Stage 1: Build ──────────────────────────────
FROM node:20-alpine AS builder

WORKDIR /app

COPY package.json package-lock.json ./
RUN npm ci

COPY . .

# Build-time environment variables
ARG VITE_API_URL=/api
ENV VITE_API_URL=$VITE_API_URL

RUN npm run build

# ── Stage 2: Serve with Nginx ──────────────────
FROM nginx:alpine AS production

# Remove default nginx config
RUN rm /etc/nginx/conf.d/default.conf

# Copy custom nginx config
COPY nginx.conf /etc/nginx/conf.d/

# Copy built React app
COPY --from=builder /app/dist /usr/share/nginx/html

# Expose port
EXPOSE 80

CMD ["nginx", "-g", "daemon off;"]

Frontend Nginx Config

# frontend/nginx.conf

server {
    listen 80;
    server_name _;
    root /usr/share/nginx/html;
    index index.html;

    # Enable gzip compression
    gzip on;
    gzip_types text/plain text/css application/json application/javascript text/xml;
    gzip_min_length 1000;

    # Cache static assets aggressively
    location /assets/ {
        expires 1y;
        add_header Cache-Control "public, immutable";
    }

    # SPA fallback — all routes serve index.html
    location / {
        try_files $uri $uri/ /index.html;
    }
}

Docker Compose: Full Stack

Now we orchestrate everything with Docker Compose:

# docker-compose.yml

services:
  # ── PostgreSQL ─────────────────────────────────
  postgres:
    image: postgres:16-alpine
    container_name: url-shortener-db
    environment:
      POSTGRES_DB: url_shortener
      POSTGRES_USER: ${DB_USER:-postgres}
      POSTGRES_PASSWORD: ${DB_PASSWORD:?Database password required}
    volumes:
      - postgres_data:/var/lib/postgresql/data
    ports:
      - "5432:5432"
    healthcheck:
      test: ["CMD-SHELL", "pg_isready -U ${DB_USER:-postgres} -d url_shortener"]
      interval: 10s
      timeout: 5s
      retries: 5
    restart: unless-stopped

  # ── Redis ──────────────────────────────────────
  redis:
    image: redis:7-alpine
    container_name: url-shortener-redis
    command: redis-server --requirepass ${REDIS_PASSWORD:?Redis password required}
    volumes:
      - redis_data:/data
    ports:
      - "6379:6379"
    healthcheck:
      test: ["CMD", "redis-cli", "-a", "${REDIS_PASSWORD}", "ping"]
      interval: 10s
      timeout: 5s
      retries: 5
    restart: unless-stopped

  # ── API Server ─────────────────────────────────
  api:
    build:
      context: .
      dockerfile: Dockerfile
    container_name: url-shortener-api
    environment:
      NODE_ENV: production
      PORT: 3000
      DATABASE_URL: postgresql://${DB_USER:-postgres}:${DB_PASSWORD}@postgres:5432/url_shortener
      REDIS_URL: redis://:${REDIS_PASSWORD}@redis:6379
      JWT_SECRET: ${JWT_SECRET:?JWT secret required}
      CORS_ORIGIN: ${CORS_ORIGIN:-https://yourdomain.com}
      BASE_URL: ${BASE_URL:-https://yourdomain.com}
    ports:
      - "3000:3000"
    depends_on:
      postgres:
        condition: service_healthy
      redis:
        condition: service_healthy
    restart: unless-stopped

  # ── Frontend ───────────────────────────────────
  frontend:
    build:
      context: ./frontend
      dockerfile: Dockerfile
      args:
        VITE_API_URL: /api
    container_name: url-shortener-frontend
    ports:
      - "8080:80"
    restart: unless-stopped

  # ── Nginx Reverse Proxy ────────────────────────
  nginx:
    image: nginx:alpine
    container_name: url-shortener-nginx
    ports:
      - "80:80"
      - "443:443"
    volumes:
      - ./nginx/nginx.conf:/etc/nginx/nginx.conf:ro
      - ./nginx/ssl:/etc/nginx/ssl:ro
    depends_on:
      - api
      - frontend
    restart: unless-stopped

  # ── Prometheus ─────────────────────────────────
  prometheus:
    image: prom/prometheus:latest
    container_name: url-shortener-prometheus
    volumes:
      - ./monitoring/prometheus.yml:/etc/prometheus/prometheus.yml:ro
      - prometheus_data:/prometheus
    ports:
      - "9090:9090"
    restart: unless-stopped

  # ── Grafana ────────────────────────────────────
  grafana:
    image: grafana/grafana:latest
    container_name: url-shortener-grafana
    environment:
      GF_SECURITY_ADMIN_PASSWORD: ${GRAFANA_PASSWORD:-admin}
    volumes:
      - grafana_data:/var/lib/grafana
    ports:
      - "3001:3000"
    depends_on:
      - prometheus
    restart: unless-stopped

volumes:
  postgres_data:
  redis_data:
  prometheus_data:
  grafana_data:

Starting the Stack

# Create .env file for production secrets
cat > .env << 'EOF'
DB_USER=postgres
DB_PASSWORD=your-secure-db-password
REDIS_PASSWORD=your-secure-redis-password
JWT_SECRET=your-secure-jwt-secret-at-least-32-chars
CORS_ORIGIN=https://yourdomain.com
BASE_URL=https://yourdomain.com
GRAFANA_PASSWORD=your-grafana-password
EOF

# Start everything
docker compose up -d --build

# Run database migrations
docker compose exec api npx prisma migrate deploy

# Check all services are healthy
docker compose ps

Expected output:

NAME                       STATUS                    PORTS
url-shortener-api          Up (healthy)              0.0.0.0:3000->3000/tcp
url-shortener-db           Up (healthy)              0.0.0.0:5432->5432/tcp
url-shortener-redis        Up (healthy)              0.0.0.0:6379->6379/tcp
url-shortener-frontend     Up                        0.0.0.0:8080->80/tcp
url-shortener-nginx        Up                        0.0.0.0:80->80/tcp, 0.0.0.0:443->443/tcp
url-shortener-prometheus   Up                        0.0.0.0:9090->9090/tcp
url-shortener-grafana      Up                        0.0.0.0:3001->3000/tcp

Environment Variable Management

Never hardcode secrets. Here's a clean pattern for managing environment variables across environments:

.env.example

# .env.example — commit this to git (no real values!)

# Database
DB_USER=postgres
DB_PASSWORD=change-me
DATABASE_URL=postgresql://postgres:change-me@localhost:5432/url_shortener

# Redis
REDIS_PASSWORD=change-me
REDIS_URL=redis://:change-me@localhost:6379

# Auth
JWT_SECRET=change-me-to-at-least-32-characters

# App
NODE_ENV=production
PORT=3000
BASE_URL=https://yourdomain.com
CORS_ORIGIN=https://yourdomain.com

# Monitoring
GRAFANA_PASSWORD=admin

Environment Validation at Startup

// src/config/env.ts

import { z } from 'zod';

const envSchema = z.object({
  NODE_ENV: z.enum(['development', 'production', 'test']).default('development'),
  PORT: z.coerce.number().default(3000),
  DATABASE_URL: z.string().url(),
  REDIS_URL: z.string().url(),
  JWT_SECRET: z.string().min(32, 'JWT_SECRET must be at least 32 characters'),
  BASE_URL: z.string().url(),
  CORS_ORIGIN: z.string(),
});

const parsed = envSchema.safeParse(process.env);

if (!parsed.success) {
  console.error('❌ Invalid environment variables:');
  console.error(parsed.error.format());
  process.exit(1);
}

export const env = parsed.data;

Fail fast. If a required environment variable is missing, the server refuses to start with a clear error message. This is much better than discovering a undefined at 3 AM in production.

Health Check Endpoints

A basic /health endpoint isn't enough for production. We need to know if our dependencies are healthy too.

// src/routes/healthRoutes.ts

import { Router, Request, Response } from 'express';
import { PrismaClient } from '@prisma/client';
import { redisClient } from '../config/redis';

const router = Router();
const prisma = new PrismaClient();

interface HealthStatus {
  status: 'healthy' | 'degraded' | 'unhealthy';
  timestamp: string;
  uptime: number;
  version: string;
  checks: {
    database: ComponentHealth;
    redis: ComponentHealth;
  };
}

interface ComponentHealth {
  status: 'up' | 'down';
  latency?: number;
  error?: string;
}

async function checkDatabase(): Promise<ComponentHealth> {
  const start = Date.now();
  try {
    await prisma.$queryRaw`SELECT 1`;
    return { status: 'up', latency: Date.now() - start };
  } catch (error) {
    return {
      status: 'down',
      latency: Date.now() - start,
      error: error instanceof Error ? error.message : 'Unknown error',
    };
  }
}

async function checkRedis(): Promise<ComponentHealth> {
  const start = Date.now();
  try {
    await redisClient.ping();
    return { status: 'up', latency: Date.now() - start };
  } catch (error) {
    return {
      status: 'down',
      latency: Date.now() - start,
      error: error instanceof Error ? error.message : 'Unknown error',
    };
  }
}

// Simple liveness probe — is the process running?
router.get('/health/live', (_req: Request, res: Response) => {
  res.json({ status: 'ok' });
});

// Readiness probe — can this instance serve traffic?
router.get('/health/ready', async (_req: Request, res: Response) => {
  const [database, redis] = await Promise.all([
    checkDatabase(),
    checkRedis(),
  ]);

  const allUp = database.status === 'up' && redis.status === 'up';

  const health: HealthStatus = {
    status: allUp ? 'healthy' : database.status === 'down' ? 'unhealthy' : 'degraded',
    timestamp: new Date().toISOString(),
    uptime: process.uptime(),
    version: process.env.npm_package_version || '1.0.0',
    checks: { database, redis },
  };

  res.status(allUp ? 200 : 503).json(health);
});

export default router;

Two endpoints, two purposes:

/health/live — Kubernetes liveness probe. If this fails, restart the container.
/health/ready — Kubernetes readiness probe. If this fails, stop routing traffic to this instance but don't restart it.

Example response when everything is healthy:

{
  "status": "healthy",
  "timestamp": "2026-03-21T10:00:00.000Z",
  "uptime": 3600,
  "version": "1.0.0",
  "checks": {
    "database": { "status": "up", "latency": 2 },
    "redis": { "status": "up", "latency": 1 }
  }
}

Example response when Redis is down:

{
  "status": "degraded",
  "timestamp": "2026-03-21T10:00:00.000Z",
  "uptime": 3600,
  "version": "1.0.0",
  "checks": {
    "database": { "status": "up", "latency": 2 },
    "redis": { "status": "down", "latency": 5000, "error": "Connection refused" }
  }
}

// src/app.ts (add to existing app setup)

import healthRoutes from './routes/healthRoutes';

// Health checks — no auth required, no rate limiting
app.use(healthRoutes);

Structured Logging with Pino

console.log is fine for development. In production, you need structured JSON logs that can be parsed by log aggregation tools like ELK Stack, Datadog, or CloudWatch.

Install Pino

npm install pino pino-http
npm install -D pino-pretty  # Pretty printing for development

Logger Setup

// src/config/logger.ts

import pino from 'pino';
import { env } from './env';

export const logger = pino({
  level: env.NODE_ENV === 'production' ? 'info' : 'debug',
  transport: env.NODE_ENV === 'development'
    ? { target: 'pino-pretty', options: { colorize: true } }
    : undefined,
  base: {
    service: 'url-shortener',
    environment: env.NODE_ENV,
  },
  serializers: {
    err: pino.stdSerializers.err,
    req: pino.stdSerializers.req,
    res: pino.stdSerializers.res,
  },
  // Redact sensitive fields
  redact: ['req.headers.authorization', 'req.headers.cookie'],
});

HTTP Request Logging

// src/middleware/requestLogger.ts

import pinoHttp from 'pino-http';
import { logger } from '../config/logger';

export const requestLogger = pinoHttp({
  logger,
  // Don't log health check requests (too noisy)
  autoLogging: {
    ignore: (req) => req.url === '/health/live' || req.url === '/health/ready',
  },
  customSuccessMessage: (req, res) => {
    return `${req.method} ${req.url} ${res.statusCode}`;
  },
  customErrorMessage: (req, res) => {
    return `${req.method} ${req.url} ${res.statusCode} ERROR`;
  },
  // Add custom properties to each log line
  customProps: (req) => ({
    requestId: req.headers['x-request-id'] || crypto.randomUUID(),
  }),
});

Using the Logger

// Replace console.log everywhere
import { logger } from '../config/logger';

// Structured log with context
logger.info({ shortCode: 'abc123', userId: 'user-1' }, 'URL shortened successfully');

// Error with stack trace
logger.error({ err: error, shortCode: 'abc123' }, 'Failed to resolve short code');

// Performance timing
const start = Date.now();
await someOperation();
logger.info({ duration: Date.now() - start }, 'Database query completed');

Production log output (JSON — one line per entry):

{"level":30,"time":1711018800000,"service":"url-shortener","environment":"production","requestId":"550e8400-e29b-41d4-a716-446655440000","shortCode":"abc123","msg":"URL shortened successfully"}

Development log output (pretty printed):

[10:00:00] INFO (url-shortener): URL shortened successfully
    shortCode: "abc123"
    userId: "user-1"

Add the request logger to your app:

// src/app.ts

import { requestLogger } from './middleware/requestLogger';

app.use(requestLogger);

Prometheus Metrics

Prometheus scrapes a /metrics endpoint on your server and stores time-series data. You then query it with Grafana for dashboards and alerts.

Install prom-client

npm install prom-client

Metrics Setup

// src/config/metrics.ts

import client from 'prom-client';

// Collect default Node.js metrics (memory, CPU, event loop)
client.collectDefaultMetrics({ prefix: 'urlshortener_' });

// ── Custom Metrics ────────────────────────────────

// HTTP request duration
export const httpRequestDuration = new client.Histogram({
  name: 'urlshortener_http_request_duration_seconds',
  help: 'Duration of HTTP requests in seconds',
  labelNames: ['method', 'route', 'status_code'],
  buckets: [0.001, 0.005, 0.01, 0.05, 0.1, 0.5, 1, 5],
});

// Total URLs shortened
export const urlsShortenedTotal = new client.Counter({
  name: 'urlshortener_urls_shortened_total',
  help: 'Total number of URLs shortened',
  labelNames: ['type'], // 'random' or 'custom_alias'
});

// Total redirects served
export const redirectsTotal = new client.Counter({
  name: 'urlshortener_redirects_total',
  help: 'Total number of redirects served',
  labelNames: ['status'], // 'success', 'not_found', 'expired'
});

// Cache hit/miss ratio
export const cacheOperations = new client.Counter({
  name: 'urlshortener_cache_operations_total',
  help: 'Redis cache operations',
  labelNames: ['operation'], // 'hit', 'miss', 'set', 'delete'
});

// Active database connections
export const dbConnections = new client.Gauge({
  name: 'urlshortener_db_connections_active',
  help: 'Number of active database connections',
});

// Request size
export const requestSize = new client.Histogram({
  name: 'urlshortener_request_size_bytes',
  help: 'Size of HTTP requests in bytes',
  buckets: [100, 500, 1000, 5000, 10000],
});

// Expose the registry for the /metrics endpoint
export const register = client.register;

Metrics Middleware

// src/middleware/metricsMiddleware.ts

import { Request, Response, NextFunction } from 'express';
import { httpRequestDuration, requestSize } from '../config/metrics';

export function metricsMiddleware(req: Request, res: Response, next: NextFunction) {
  const start = Date.now();

  // Track request size
  const contentLength = parseInt(req.headers['content-length'] || '0', 10);
  if (contentLength > 0) {
    requestSize.observe(contentLength);
  }

  // Track response time when response finishes
  res.on('finish', () => {
    const duration = (Date.now() - start) / 1000;
    const route = req.route?.path || req.path;

    httpRequestDuration
      .labels(req.method, route, res.statusCode.toString())
      .observe(duration);
  });

  next();
}

Metrics Endpoint

// src/routes/metricsRoutes.ts

import { Router, Request, Response } from 'express';
import { register } from '../config/metrics';

const router = Router();

router.get('/metrics', async (_req: Request, res: Response) => {
  try {
    res.set('Content-Type', register.contentType);
    res.end(await register.metrics());
  } catch (error) {
    res.status(500).end();
  }
});

export default router;

Instrument Your Services

Add metric tracking to your URL service:

// src/services/urlService.ts (add to existing methods)

import { urlsShortenedTotal, redirectsTotal, cacheOperations } from '../config/metrics';

async shortenUrl(url: string, customAlias?: string) {
  // ... existing logic ...

  urlsShortenedTotal.labels(customAlias ? 'custom_alias' : 'random').inc();

  return result;
}

async resolveAndTrack(shortCode: string) {
  // Check cache first
  const cached = await redisClient.get(`url:${shortCode}`);

  if (cached) {
    cacheOperations.labels('hit').inc();
    redirectsTotal.labels('success').inc();
    return cached;
  }

  cacheOperations.labels('miss').inc();

  // ... database lookup ...

  if (!url) {
    redirectsTotal.labels('not_found').inc();
    return null;
  }

  // Cache for next time
  await redisClient.setex(`url:${shortCode}`, 3600, url.originalUrl);
  cacheOperations.labels('set').inc();
  redirectsTotal.labels('success').inc();

  return url.originalUrl;
}

// src/app.ts

import { metricsMiddleware } from './middleware/metricsMiddleware';
import metricsRoutes from './routes/metricsRoutes';

app.use(metricsMiddleware);
app.use(metricsRoutes);

Prometheus Configuration

# monitoring/prometheus.yml

global:
  scrape_interval: 15s
  evaluation_interval: 15s

scrape_configs:
  - job_name: 'url-shortener-api'
    metrics_path: '/metrics'
    static_configs:
      - targets: ['api:3000']
        labels:
          app: 'url-shortener'
          environment: 'production'

  - job_name: 'node-exporter'
    static_configs:
      - targets: ['node-exporter:9100']

Visit http://localhost:9090 to access the Prometheus UI and query your metrics.

Grafana Dashboard Setup

1. Add Prometheus as Data Source

Open Grafana at http://localhost:3001
Login with admin / your GRAFANA_PASSWORD
Go to Configuration > Data Sources > Add data source
Select Prometheus
Set URL to http://prometheus:9090
Click Save & Test

2. Create the Dashboard

Create a JSON dashboard definition for import:

{
  "dashboard": {
    "title": "URL Shortener Dashboard",
    "panels": [
      {
        "title": "Request Rate (req/sec)",
        "type": "graph",
        "targets": [{
          "expr": "rate(urlshortener_http_request_duration_seconds_count[5m])",
          "legendFormat": "{{method}} {{route}}"
        }]
      },
      {
        "title": "Response Time (p95)",
        "type": "graph",
        "targets": [{
          "expr": "histogram_quantile(0.95, rate(urlshortener_http_request_duration_seconds_bucket[5m]))",
          "legendFormat": "p95 latency"
        }]
      },
      {
        "title": "URLs Shortened",
        "type": "stat",
        "targets": [{
          "expr": "urlshortener_urls_shortened_total"
        }]
      },
      {
        "title": "Cache Hit Rate",
        "type": "gauge",
        "targets": [{
          "expr": "rate(urlshortener_cache_operations_total{operation='hit'}[5m]) / (rate(urlshortener_cache_operations_total{operation='hit'}[5m]) + rate(urlshortener_cache_operations_total{operation='miss'}[5m])) * 100"
        }]
      },
      {
        "title": "Redirects per Second",
        "type": "graph",
        "targets": [{
          "expr": "rate(urlshortener_redirects_total[5m])",
          "legendFormat": "{{status}}"
        }]
      }
    ]
  }
}

Key Metrics to Monitor

Metric	What it tells you	Alert threshold
Request rate	Traffic volume	Spike > 10x normal
p95 latency	User experience	> 500ms
Error rate	Application health	> 1% of requests
Cache hit rate	Redis effectiveness	< 80%
DB connection pool	Database health	> 80% pool used
Memory usage	Resource consumption	> 80% of limit
Redirect latency	Core feature performance	> 50ms

Production Hardening

Security Middleware

npm install helmet cors compression
npm install -D @types/cors @types/compression

// src/middleware/security.ts

import helmet from 'helmet';
import cors from 'cors';
import compression from 'compression';
import { env } from '../config/env';

// Helmet sets security headers
export const securityHeaders = helmet({
  contentSecurityPolicy: {
    directives: {
      defaultSrc: ["'self'"],
      scriptSrc: ["'self'"],
      styleSrc: ["'self'", "'unsafe-inline'"],
      imgSrc: ["'self'", 'data:', 'https:'],
    },
  },
  // HSTS — force HTTPS
  hsts: {
    maxAge: 31536000, // 1 year
    includeSubDomains: true,
    preload: true,
  },
});

// CORS — restrict which origins can call your API
export const corsMiddleware = cors({
  origin: env.CORS_ORIGIN.split(','),
  methods: ['GET', 'POST', 'PUT', 'DELETE'],
  allowedHeaders: ['Content-Type', 'Authorization'],
  credentials: true,
  maxAge: 86400, // Cache preflight for 24 hours
});

// Compression — gzip responses to reduce bandwidth
export const compressionMiddleware = compression({
  // Don't compress responses smaller than 1KB
  threshold: 1024,
  // Don't compress if client doesn't accept it
  filter: (req, res) => {
    if (req.headers['x-no-compression']) return false;
    return compression.filter(req, res);
  },
});

Apply Security Middleware

// src/app.ts

import { securityHeaders, corsMiddleware, compressionMiddleware } from './middleware/security';

const app = express();

// Security middleware — apply FIRST
app.use(securityHeaders);
app.use(corsMiddleware);
app.use(compressionMiddleware);

// Then your existing middleware
app.use(express.json({ limit: '10kb' }));
app.use(requestLogger);
app.use(metricsMiddleware);

// ... routes

Graceful Shutdown

Update your server entry point to handle shutdown signals properly:

// src/index.ts

import app from './app';
import { env } from './config/env';
import { logger } from './config/logger';
import { PrismaClient } from '@prisma/client';
import { redisClient } from './config/redis';

const prisma = new PrismaClient();

const server = app.listen(env.PORT, () => {
  logger.info({ port: env.PORT, env: env.NODE_ENV }, 'Server started');
});

// Graceful shutdown
async function shutdown(signal: string) {
  logger.info({ signal }, 'Shutdown signal received');

  // Stop accepting new connections
  server.close(async () => {
    logger.info('HTTP server closed');

    // Close database connection
    await prisma.$disconnect();
    logger.info('Database connection closed');

    // Close Redis connection
    await redisClient.quit();
    logger.info('Redis connection closed');

    process.exit(0);
  });

  // Force exit after 30 seconds
  setTimeout(() => {
    logger.error('Forced shutdown after timeout');
    process.exit(1);
  }, 30000);
}

process.on('SIGTERM', () => shutdown('SIGTERM'));
process.on('SIGINT', () => shutdown('SIGINT'));

// Handle uncaught errors
process.on('uncaughtException', (error) => {
  logger.fatal({ err: error }, 'Uncaught exception');
  process.exit(1);
});

process.on('unhandledRejection', (reason) => {
  logger.fatal({ err: reason }, 'Unhandled rejection');
  process.exit(1);
});

Why graceful shutdown matters: Without it, a deploy kills in-flight requests. Users see 502 errors. Database connections leak. With graceful shutdown, the server finishes processing current requests, closes connections cleanly, and then exits.

Nginx Reverse Proxy

Nginx sits in front of everything, handling SSL termination, static file serving, and request routing.

# nginx/nginx.conf

events {
    worker_connections 1024;
}

http {
    # Rate limiting zone
    limit_req_zone $binary_remote_addr zone=api:10m rate=10r/s;

    # Logging format
    log_format main '$remote_addr - $remote_user [$time_local] '
                    '"$request" $status $body_bytes_sent '
                    '"$http_referer" "$http_user_agent" '
                    '$request_time';

    upstream api_backend {
        server api:3000;
    }

    upstream frontend_backend {
        server frontend:80;
    }

    server {
        listen 80;
        server_name yourdomain.com;

        # Redirect HTTP to HTTPS
        return 301 https://$server_name$request_uri;
    }

    server {
        listen 443 ssl http2;
        server_name yourdomain.com;

        # SSL certificates (use Let's Encrypt / certbot)
        ssl_certificate /etc/nginx/ssl/fullchain.pem;
        ssl_certificate_key /etc/nginx/ssl/privkey.pem;
        ssl_protocols TLSv1.2 TLSv1.3;
        ssl_ciphers HIGH:!aNULL:!MD5;

        # Security headers
        add_header X-Frame-Options DENY;
        add_header X-Content-Type-Options nosniff;
        add_header X-XSS-Protection "1; mode=block";

        # Gzip compression
        gzip on;
        gzip_types text/plain text/css application/json application/javascript;
        gzip_min_length 1000;

        # API routes
        location /api/ {
            limit_req zone=api burst=20 nodelay;
            proxy_pass http://api_backend;
            proxy_set_header Host $host;
            proxy_set_header X-Real-IP $remote_addr;
            proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
            proxy_set_header X-Forwarded-Proto $scheme;
        }

        # Short code redirects (single path segment, not starting with api/health/metrics)
        location ~ ^/[a-zA-Z0-9]{5,10}$ {
            proxy_pass http://api_backend;
            proxy_set_header Host $host;
            proxy_set_header X-Real-IP $remote_addr;
            proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
            proxy_set_header X-Forwarded-Proto $scheme;
        }

        # Health checks (no rate limiting)
        location /health/ {
            proxy_pass http://api_backend;
        }

        # Metrics (restrict to internal network)
        location /metrics {
            allow 10.0.0.0/8;
            allow 172.16.0.0/12;
            deny all;
            proxy_pass http://api_backend;
        }

        # Frontend (everything else)
        location / {
            proxy_pass http://frontend_backend;
            proxy_set_header Host $host;
        }
    }
}

Key decisions:

SSL termination at Nginx — API and frontend don't need to handle HTTPS
Rate limiting at Nginx — first line of defense before requests reach your app
Metrics restricted to internal network — don't expose Prometheus data publicly
Short code regex — routes like /aBc123 go to the API, everything else to the frontend

GitHub Actions CI/CD Pipeline

Automate everything: lint, test, build, and deploy on every push.

# .github/workflows/ci-cd.yml

name: CI/CD Pipeline

on:
  push:
    branches: [main]
  pull_request:
    branches: [main]

env:
  REGISTRY: ghcr.io
  IMAGE_NAME: ${{ github.repository }}

jobs:
  # ── Lint & Type Check ──────────────────────────
  lint:
    name: Lint & Type Check
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v4

      - uses: actions/setup-node@v4
        with:
          node-version: 20
          cache: 'npm'

      - run: npm ci
      - run: npm run lint
      - run: npx tsc --noEmit

  # ── Unit & Integration Tests ───────────────────
  test:
    name: Test
    runs-on: ubuntu-latest
    needs: lint

    services:
      postgres:
        image: postgres:16-alpine
        env:
          POSTGRES_DB: url_shortener_test
          POSTGRES_USER: postgres
          POSTGRES_PASSWORD: test-password
        ports:
          - 5432:5432
        options: >-
          --health-cmd pg_isready
          --health-interval 10s
          --health-timeout 5s
          --health-retries 5

      redis:
        image: redis:7-alpine
        ports:
          - 6379:6379
        options: >-
          --health-cmd "redis-cli ping"
          --health-interval 10s
          --health-timeout 5s
          --health-retries 5

    steps:
      - uses: actions/checkout@v4

      - uses: actions/setup-node@v4
        with:
          node-version: 20
          cache: 'npm'

      - run: npm ci
      - run: npx prisma generate
      - run: npx prisma migrate deploy
        env:
          DATABASE_URL: postgresql://postgres:test-password@localhost:5432/url_shortener_test

      - run: npm test -- --coverage
        env:
          DATABASE_URL: postgresql://postgres:test-password@localhost:5432/url_shortener_test
          REDIS_URL: redis://localhost:6379
          JWT_SECRET: test-secret-at-least-32-characters-long
          NODE_ENV: test

      - name: Upload coverage
        uses: actions/upload-artifact@v4
        with:
          name: coverage
          path: coverage/

  # ── Build Docker Image ─────────────────────────
  build:
    name: Build & Push Docker Image
    runs-on: ubuntu-latest
    needs: test
    if: github.ref == 'refs/heads/main'

    permissions:
      contents: read
      packages: write

    steps:
      - uses: actions/checkout@v4

      - name: Log in to Container Registry
        uses: docker/login-action@v3
        with:
          registry: ${{ env.REGISTRY }}
          username: ${{ github.actor }}
          password: ${{ secrets.GITHUB_TOKEN }}

      - name: Build and push API image
        uses: docker/build-push-action@v5
        with:
          context: .
          push: true
          tags: |
            ${{ env.REGISTRY }}/${{ env.IMAGE_NAME }}-api:latest
            ${{ env.REGISTRY }}/${{ env.IMAGE_NAME }}-api:${{ github.sha }}

      - name: Build and push Frontend image
        uses: docker/build-push-action@v5
        with:
          context: ./frontend
          push: true
          tags: |
            ${{ env.REGISTRY }}/${{ env.IMAGE_NAME }}-frontend:latest
            ${{ env.REGISTRY }}/${{ env.IMAGE_NAME }}-frontend:${{ github.sha }}

  # ── Deploy ─────────────────────────────────────
  deploy:
    name: Deploy to Production
    runs-on: ubuntu-latest
    needs: build
    if: github.ref == 'refs/heads/main'
    environment: production

    steps:
      - name: Deploy via SSH
        uses: appleboy/ssh-action@v1
        with:
          host: ${{ secrets.SERVER_HOST }}
          username: ${{ secrets.SERVER_USER }}
          key: ${{ secrets.SSH_PRIVATE_KEY }}
          script: |
            cd /opt/url-shortener

            # Pull latest images
            docker compose pull

            # Run database migrations
            docker compose run --rm api npx prisma migrate deploy

            # Restart with zero downtime
            docker compose up -d --remove-orphans

            # Verify deployment
            sleep 5
            curl -f http://localhost:3000/health/ready || exit 1

            echo "✅ Deployment successful"

CI/CD Flow

Required GitHub Secrets

Secret	Description
`SERVER_HOST`	Production server IP or hostname
`SERVER_USER`	SSH username
`SSH_PRIVATE_KEY`	SSH private key for deployment

The GITHUB_TOKEN is automatically available — no setup needed for GitHub Container Registry.

Production Checklist

Before going live, verify everything on this list:

Security

All secrets in environment variables (not in code)
Helmet security headers enabled
CORS restricted to your domain
Rate limiting on API endpoints
Non-root user in Docker containers
SSL/TLS configured (HTTPS only)
/metrics endpoint restricted to internal network

Reliability

Health check endpoints responding
Graceful shutdown handling SIGTERM
Database connection pooling configured
Redis connection with retry logic
Uncaught exception handlers
Docker healthchecks for all services

Observability

Structured JSON logging (no console.log)
Request/response logging with correlation IDs
Prometheus metrics exposed
Grafana dashboard configured
Key metrics: latency, error rate, cache hit rate

Performance

Gzip compression enabled
Multi-stage Docker builds (small images)
Static assets cached with long expiry
Database queries indexed
Redis caching on hot paths

CI/CD

Automated linting and type checking
Test suite runs on every PR
Docker images built and pushed automatically
Zero-downtime deployment
Rollback strategy documented

Deployment Commands Cheat Sheet

# ── Local Development ────────────────────────────
docker compose up -d postgres redis     # Start dependencies only
npm run dev                              # Run API with hot reload

# ── Full Stack (Local) ───────────────────────────
docker compose up -d --build             # Build and start everything
docker compose logs -f api               # Follow API logs
docker compose exec api npx prisma studio  # Open Prisma Studio

# ── Production ───────────────────────────────────
docker compose -f docker-compose.yml up -d --build
docker compose exec api npx prisma migrate deploy
docker compose ps                        # Check service status

# ── Monitoring ───────────────────────────────────
curl http://localhost:3000/health/ready  # Check health
curl http://localhost:3000/metrics       # View Prometheus metrics
# Grafana: http://localhost:3001
# Prometheus: http://localhost:9090

# ── Troubleshooting ──────────────────────────────
docker compose logs api --tail 100       # Last 100 API log lines
docker compose exec postgres psql -U postgres -d url_shortener  # DB shell
docker compose exec redis redis-cli      # Redis shell
docker compose restart api               # Restart API only

Series Recap: What We Built

Over 10 posts, we built a production-ready URL shortener from an empty directory. Let's look back at what each phase taught us:

Post	Phase	Key Concepts
#1	Series Overview	Architecture, tech stack decisions, system design
#2	Project Setup & API	Express + TypeScript, REST API design, validation
#3	Database Design	PostgreSQL, Prisma ORM, migrations, indexing
#4	Short Code Generation	Base62 encoding, collision handling, custom aliases
#5	Redirect Engine & Analytics	301/302 redirects, click tracking, aggregation
#6	Caching with Redis	Cache-aside pattern, TTL, rate limiting
#7	Authentication	JWT, bcrypt, middleware auth, API keys
#8	Frontend with React	React, Vite, charts, QR codes, dashboard
#9	Testing Strategy	Unit, integration, load testing with Vitest + k6
#10	Deployment (this post)	Docker, CI/CD, monitoring, production hardening

The Full Tech Stack

Where to Go From Here

Congratulations — you've built a complete, production-deployed application. Here are some directions to explore next:

Feature Extensions

Link expiration scheduler — background job to deactivate expired URLs
Custom domains — let users bring their own short domains
Link previews — show a preview page before redirecting
Bulk URL import — CSV upload for batch shortening
Webhooks — notify users when their links reach click milestones

Infrastructure Improvements

Kubernetes deployment — orchestrate with Helm charts
CDN integration — CloudFlare or AWS CloudFront for global edge caching
Database replicas — read replicas for analytics queries
Message queue — RabbitMQ or Kafka for async click processing
Blue-green deployments — zero-downtime releases with traffic switching

Learning Paths

System design interviews — you can now discuss URL shorteners with real implementation experience
Microservices — split the monolith into separate services (redirect service, analytics service, auth service)
Serverless — rewrite the redirect engine as a Cloudflare Worker for edge performance
Open source — publish your shortener and accept contributions

The skills you've learned — API design, database modeling, caching, auth, testing, containerization, CI/CD, monitoring — are the same skills used to build systems at every scale. But we're not done yet — in the next phase, we'll add an admin panel with role-based access control and user management.

Series: Build a URL Shortener
Previous: Phase 8: Testing Strategy
Next: Phase 10: Admin Panel — RBAC & User Management
