Kubernetes Fundamentals

Welcome to Phase 3 of the Docker & Kubernetes Learning Roadmap! You've mastered Docker fundamentals, written Dockerfiles, and orchestrated multi-container apps with Docker Compose. Now it's time for the big leap — Kubernetes.

Docker Compose is great for single-machine deployments. But what happens when your app needs to run across multiple servers? When a container crashes at 3 AM and nobody's awake to restart it? When Black Friday traffic hits and you need 50 replicas instead of 2? That's where Kubernetes comes in.

What You'll Learn

✅ Understand Kubernetes architecture (control plane and worker nodes)
✅ Set up a local Kubernetes cluster with minikube
✅ Create and manage Pods — the smallest deployable unit
✅ Use Deployments for rolling updates and rollbacks
✅ Expose applications with Services (ClusterIP, NodePort, LoadBalancer)
✅ Manage configuration with ConfigMaps and Secrets
✅ Organize resources with Namespaces, Labels, and Selectors
✅ Debug and troubleshoot Kubernetes workloads

Time commitment: 7–10 days, 1–2 hours daily
Prerequisites: Phase 2: Docker Compose & Multi-Container Apps

Part 1: What is Kubernetes?

Kubernetes (often abbreviated as K8s — the 8 stands for the eight letters between "K" and "s") is an open-source container orchestration platform. Originally designed by Google and now maintained by the Cloud Native Computing Foundation (CNCF), it automates deploying, scaling, and managing containerized applications.

Why Kubernetes?

Docker runs containers. Kubernetes runs containers at scale. Here's what it gives you:

Capability	Without K8s	With K8s
Scaling	Manually start more containers	`kubectl scale --replicas=10`
Self-healing	Container crashes → you restart it	K8s automatically restarts failed containers
Load balancing	Set up nginx/HAProxy yourself	Built-in Service load balancing
Rolling updates	Stop old → start new (downtime)	Zero-downtime rolling deployments
Service discovery	Hardcode IPs or use external DNS	Built-in DNS for every Service
Configuration	Environment files on each server	Centralized ConfigMaps and Secrets
Resource management	Hope containers don't hog resources	CPU/memory requests and limits

Kubernetes vs Docker Compose vs Docker Swarm

Feature	Docker Compose	Docker Swarm	Kubernetes
Complexity	Simple	Moderate	Complex
Multi-node	No	Yes	Yes
Auto-scaling	No	Limited	Advanced (HPA, VPA)
Self-healing	No	Basic	Advanced
Ecosystem	Docker only	Docker only	Massive (CNCF)
Learning curve	Low	Medium	High
Best for	Development	Small production	Large-scale production

Kubernetes Distributions

Not all Kubernetes is the same. There are several distributions:

Vanilla Kubernetes (kubeadm) — The standard, DIY installation
minikube — Single-node cluster for local development
kind (Kubernetes in Docker) — Runs K8s nodes as Docker containers
k3s — Lightweight K8s by Rancher (great for edge/IoT)
MicroK8s — Canonical's lightweight K8s (snap-based)
OpenShift — Red Hat's enterprise Kubernetes platform
Managed services — EKS (AWS), GKE (Google), AKS (Azure)

For learning, we'll use minikube — it's the easiest way to get a full Kubernetes cluster running on your laptop.

Part 2: Kubernetes Architecture

Understanding Kubernetes architecture is essential before you start deploying anything. A Kubernetes cluster has two main parts: the control plane and the worker nodes.

Control Plane Components

The control plane is the "brain" of the cluster. It makes decisions about scheduling, detecting events, and responding to changes.

API Server (kube-apiserver)

The front door to Kubernetes — every command goes through it
kubectl communicates with the API server
RESTful API that validates and processes requests
The only component that talks to etcd directly

etcd

Distributed key-value store that holds all cluster state
Stores configuration, secrets, service discovery data
If etcd dies, your cluster loses its memory
Always run with backups in production

Scheduler (kube-scheduler)

Decides which node should run a new Pod
Considers: resource requirements, affinity rules, taints/tolerations
Doesn't run the Pod — just assigns it to a node

Controller Manager (kube-controller-manager)

Runs controller loops that watch cluster state and make corrections
Deployment controller: ensures desired replicas are running
Node controller: monitors node health
Job controller: manages batch jobs

Worker Node Components

Worker nodes are the machines that actually run your containers.

kubelet

Agent that runs on every worker node
Receives Pod specs from the API server
Ensures containers are running and healthy
Reports node and Pod status back to the control plane

kube-proxy

Network proxy on each node
Maintains network rules for Service communication
Implements the Service abstraction (load balancing between Pods)

Container Runtime

The software that runs containers (containerd, CRI-O)
Docker was the original runtime but Kubernetes removed Docker support in v1.24
containerd is now the most common runtime

How It All Fits Together

When you run kubectl apply -f deployment.yaml, here's what happens:

Part 3: Setting Up Kubernetes

Installing minikube

minikube creates a single-node Kubernetes cluster on your local machine.

macOS:

# Install with Homebrew
brew install minikube

# Or download directly
curl -LO https://storage.googleapis.com/minikube/releases/latest/minikube-darwin-arm64
sudo install minikube-darwin-arm64 /usr/local/bin/minikube

Linux:

curl -LO https://storage.googleapis.com/minikube/releases/latest/minikube-linux-amd64
sudo install minikube-linux-amd64 /usr/local/bin/minikube

Windows (PowerShell):

winget install Kubernetes.minikube

Starting Your Cluster

# Start minikube with default settings
minikube start

# Start with specific resources
minikube start --cpus=4 --memory=8192 --driver=docker

# Check cluster status
minikube status

Output:

minikube
type: Control Plane
host: Running
kubelet: Running
apiserver: Running
kubeconfig: Configured

Installing kubectl

kubectl is the command-line tool for interacting with Kubernetes.

macOS:

brew install kubectl

Linux:

curl -LO "https://dl.k8s.io/release/$(curl -L -s https://dl.k8s.io/release/stable.txt)/bin/linux/amd64/kubectl"
sudo install kubectl /usr/local/bin/kubectl

Verify installation:

# Check kubectl version
kubectl version --client

# Check cluster connection
kubectl cluster-info

# View cluster nodes
kubectl get nodes

Output:

NAME       STATUS   ROLES           AGE   VERSION
minikube   Ready    control-plane   2m    v1.31.0

kubectl Essentials

Here are the commands you'll use every day:

# Get resources
kubectl get pods                    # List all pods
kubectl get pods -o wide            # With extra details (IP, node)
kubectl get services                # List all services
kubectl get all                     # List everything

# Describe (detailed info)
kubectl describe pod <pod-name>     # Detailed pod info
kubectl describe node minikube      # Node details

# Create and apply
kubectl apply -f manifest.yaml     # Apply a manifest (create or update)
kubectl create -f manifest.yaml    # Create (fails if exists)

# Delete
kubectl delete pod <pod-name>      # Delete a pod
kubectl delete -f manifest.yaml    # Delete resources from manifest

# Logs and debugging
kubectl logs <pod-name>            # View pod logs
kubectl logs -f <pod-name>         # Stream logs (follow)
kubectl exec -it <pod-name> -- sh  # Shell into a pod

# Context management
kubectl config get-contexts        # List available contexts
kubectl config use-context minikube # Switch context

Pro tip: Set up an alias to save typing:
alias k=kubectl
Now you can type k get pods instead of kubectl get pods.

Part 4: Pods

A Pod is the smallest deployable unit in Kubernetes. It's a wrapper around one or more containers that share the same network and storage.

Why Pods, Not Containers?

In Docker, you think in terms of containers. In Kubernetes, you think in terms of Pods. Why the extra layer?

Pods can run multiple containers that need to work together (sidecar pattern)
Containers in the same Pod share the same IP address and localhost
Containers in the same Pod share volumes
Pods are the unit of scheduling — they always run on the same node

Most of the time, a Pod runs one container. Multi-container Pods are for specific patterns like logging sidecars, proxies, or init containers.

Creating Your First Pod

Imperative approach (quick testing):

# Run a pod directly
kubectl run nginx --image=nginx:alpine --port=80

# Check it's running
kubectl get pods

Output:

NAME    READY   STATUS    RESTARTS   AGE
nginx   1/1     Running   0          10s

Declarative approach (recommended):

Create a file called pod.yaml:

apiVersion: v1
kind: Pod
metadata:
  name: my-app
  labels:
    app: my-app
    environment: dev
spec:
  containers:
    - name: app
      image: nginx:alpine
      ports:
        - containerPort: 80
      resources:
        requests:
          memory: "64Mi"
          cpu: "100m"
        limits:
          memory: "128Mi"
          cpu: "250m"

Apply it:

kubectl apply -f pod.yaml
kubectl get pods
kubectl describe pod my-app

Pod Lifecycle

Pods go through several phases:

Phase	Meaning
Pending	Pod accepted but containers not running yet (pulling images, scheduling)
Running	At least one container is running
Succeeded	All containers exited successfully (exit code 0)
Failed	At least one container exited with an error
Unknown	Pod state can't be determined (usually node communication issues)

Multi-Container Pods

Sometimes containers need to work together closely. Common patterns:

Sidecar pattern — a helper container alongside the main app:

apiVersion: v1
kind: Pod
metadata:
  name: app-with-sidecar
  labels:
    app: web
spec:
  containers:
    # Main application
    - name: app
      image: nginx:alpine
      ports:
        - containerPort: 80
      volumeMounts:
        - name: shared-logs
          mountPath: /var/log/nginx

    # Sidecar: ships logs to a central system
    - name: log-shipper
      image: busybox
      command: ["sh", "-c", "tail -f /logs/access.log"]
      volumeMounts:
        - name: shared-logs
          mountPath: /logs

  volumes:
    - name: shared-logs
      emptyDir: {}

Both containers share the shared-logs volume. The nginx container writes logs, and the log-shipper container reads and forwards them.

Init Containers

Init containers run before the main containers start. They're perfect for setup tasks:

apiVersion: v1
kind: Pod
metadata:
  name: app-with-init
  labels:
    app: web
spec:
  initContainers:
    # Wait for a database to be ready
    - name: wait-for-db
      image: busybox
      command: ["sh", "-c", "until nc -z db-service 5432; do echo waiting for db; sleep 2; done"]

    # Run database migrations
    - name: run-migrations
      image: my-app:latest
      command: ["python", "manage.py", "migrate"]

  containers:
    - name: app
      image: my-app:latest
      ports:
        - containerPort: 8000

Init containers run sequentially — each must complete before the next starts. The main container only starts after all init containers succeed.

Debugging Pods

# View pod details (events at the bottom are most useful)
kubectl describe pod my-app

# View logs
kubectl logs my-app
kubectl logs my-app -c log-shipper    # Specific container in multi-container pod
kubectl logs my-app --previous        # Logs from a crashed container

# Shell into a running pod
kubectl exec -it my-app -- /bin/sh

# Port-forward to access a pod locally
kubectl port-forward my-app 8080:80
# Now visit http://localhost:8080

# Check resource usage
kubectl top pod my-app

Common Pod issues and fixes:

Status	Common Cause	Debug Command
`ImagePullBackOff`	Wrong image name or no access to registry	`kubectl describe pod` → check Events
`CrashLoopBackOff`	App crashes on startup	`kubectl logs --previous`
`Pending`	Not enough resources on nodes	`kubectl describe pod` → check Events
`OOMKilled`	Container exceeded memory limit	Increase `resources.limits.memory`

Part 5: Deployments

In practice, you almost never create Pods directly. Instead, you use a Deployment — a higher-level resource that manages Pods for you.

Why Deployments?

Feature	Bare Pod	Deployment
Self-healing	Pod dies → stays dead	Pod dies → new one created
Scaling	Manual pod creation	`kubectl scale --replicas=5`
Rolling updates	Stop old, start new	Zero-downtime updates
Rollback	Not possible	`kubectl rollout undo`
History	None	Full revision history

Creating a Deployment

apiVersion: apps/v1
kind: Deployment
metadata:
  name: my-app
  labels:
    app: my-app
spec:
  replicas: 3
  selector:
    matchLabels:
      app: my-app
  template:
    metadata:
      labels:
        app: my-app
    spec:
      containers:
        - name: app
          image: nginx:1.25-alpine
          ports:
            - containerPort: 80
          resources:
            requests:
              memory: "64Mi"
              cpu: "100m"
            limits:
              memory: "128Mi"
              cpu: "250m"
          readinessProbe:
            httpGet:
              path: /
              port: 80
            initialDelaySeconds: 5
            periodSeconds: 10
          livenessProbe:
            httpGet:
              path: /
              port: 80
            initialDelaySeconds: 15
            periodSeconds: 20

Let's break down the key parts:

replicas: 3 — Run 3 identical Pods
selector.matchLabels — How the Deployment finds its Pods
template — The Pod template (what each replica looks like)
readinessProbe — Checks if the Pod is ready to receive traffic
livenessProbe — Checks if the Pod is still alive (restarts it if not)

Apply and inspect:

kubectl apply -f deployment.yaml

# View the deployment
kubectl get deployments
kubectl get rs    # ReplicaSet created by the Deployment
kubectl get pods  # Pods created by the ReplicaSet

Output:

NAME     READY   UP-TO-DATE   AVAILABLE   AGE
my-app   3/3     3            3           30s

NAME                DESIRED   CURRENT   READY   AGE
my-app-7d9f8b6c5   3         3         3       30s

NAME                      READY   STATUS    RESTARTS   AGE
my-app-7d9f8b6c5-abc12   1/1     Running   0          30s
my-app-7d9f8b6c5-def34   1/1     Running   0          30s
my-app-7d9f8b6c5-ghi56   1/1     Running   0          30s

Notice the hierarchy: Deployment → ReplicaSet → Pods. The Deployment manages ReplicaSets, and ReplicaSets manage Pods.

Scaling

# Scale up
kubectl scale deployment my-app --replicas=5

# Scale down
kubectl scale deployment my-app --replicas=2

# Check the result
kubectl get pods

Rolling Updates

This is where Deployments shine. When you update the container image, Kubernetes gradually replaces old Pods with new ones — zero downtime.

# Update the image
kubectl set image deployment/my-app app=nginx:1.26-alpine

# Watch the rollout
kubectl rollout status deployment/my-app

What happens during a rolling update:

You can control the update strategy:

spec:
  strategy:
    type: RollingUpdate
    rollingUpdate:
      maxSurge: 1        # Max extra pods during update
      maxUnavailable: 0   # Zero downtime — never remove a pod until new one is ready

Rollbacks

Something went wrong with the new version? Roll back instantly:

# View rollout history
kubectl rollout history deployment/my-app

# Roll back to previous version
kubectl rollout undo deployment/my-app

# Roll back to a specific revision
kubectl rollout undo deployment/my-app --to-revision=2

# Check rollout status
kubectl rollout status deployment/my-app

Health Checks (Probes)

Probes tell Kubernetes whether your application is healthy:

Probe	Purpose	Action on Failure
livenessProbe	Is the container alive?	Restart the container
readinessProbe	Is the container ready for traffic?	Remove from Service endpoints
startupProbe	Has the app finished starting?	Kill and restart

containers:
  - name: app
    image: my-app:latest
    # Startup probe: give slow-starting apps time to boot
    startupProbe:
      httpGet:
        path: /healthz
        port: 8080
      failureThreshold: 30
      periodSeconds: 10

    # Liveness probe: restart if the app hangs
    livenessProbe:
      httpGet:
        path: /healthz
        port: 8080
      initialDelaySeconds: 0
      periodSeconds: 15
      failureThreshold: 3

    # Readiness probe: only send traffic when ready
    readinessProbe:
      httpGet:
        path: /ready
        port: 8080
      initialDelaySeconds: 5
      periodSeconds: 5

Part 6: Services

Pods are ephemeral — they come and go, get new IP addresses each time. You can't rely on Pod IPs. Services provide a stable network endpoint to access a group of Pods.

How Services Work

A Service uses label selectors to find Pods and routes traffic to them:

Service Types

Kubernetes offers four Service types, each with different access levels:

1. ClusterIP (default)

Only accessible within the cluster. Perfect for internal service-to-service communication.

apiVersion: v1
kind: Service
metadata:
  name: backend-service
spec:
  type: ClusterIP
  selector:
    app: backend
  ports:
    - port: 80          # Service port
      targetPort: 8080   # Container port
      protocol: TCP

Other Pods can access this service at backend-service:80 or backend-service.default.svc.cluster.local:80.

2. NodePort

Exposes the Service on a static port on every node. Accessible from outside the cluster.

apiVersion: v1
kind: Service
metadata:
  name: frontend-service
spec:
  type: NodePort
  selector:
    app: frontend
  ports:
    - port: 80
      targetPort: 3000
      nodePort: 30080    # External port (30000-32767)

Access via <node-ip>:30080. With minikube:

minikube service frontend-service --url

3. LoadBalancer

Creates an external load balancer (on cloud providers like AWS, GKE, AKS). In minikube, use minikube tunnel to simulate it.

apiVersion: v1
kind: Service
metadata:
  name: public-api
spec:
  type: LoadBalancer
  selector:
    app: api
  ports:
    - port: 80
      targetPort: 8080

# In a separate terminal (for minikube)
minikube tunnel

# Now check the external IP
kubectl get service public-api

4. ExternalName

Maps a Service to an external DNS name. No proxying — just a DNS alias.

apiVersion: v1
kind: Service
metadata:
  name: external-db
spec:
  type: ExternalName
  externalName: db.example.com

Pods can access external-db and it resolves to db.example.com.

Service Discovery

Kubernetes provides built-in DNS for Services. Every Service gets a DNS entry:

<service-name>.<namespace>.svc.cluster.local

Within the same namespace, you can just use the service name:

# Inside a Pod in the same namespace
import requests

# Short form (same namespace)
response = requests.get("http://backend-service:80/api/users")

# Full DNS name (cross-namespace)
response = requests.get("http://backend-service.production.svc.cluster.local:80/api/users")

Part 7: ConfigMaps and Secrets

Hardcoding configuration in container images is a bad practice. ConfigMaps and Secrets let you decouple configuration from your application code.

ConfigMaps

ConfigMaps store non-sensitive configuration data as key-value pairs.

Creating ConfigMaps:

# From literal values
kubectl create configmap app-config \
  --from-literal=APP_ENV=production \
  --from-literal=LOG_LEVEL=info \
  --from-literal=MAX_CONNECTIONS=100

# From a file
kubectl create configmap nginx-config --from-file=nginx.conf

# View the ConfigMap
kubectl get configmap app-config -o yaml

Declarative YAML:

apiVersion: v1
kind: ConfigMap
metadata:
  name: app-config
data:
  APP_ENV: "production"
  LOG_LEVEL: "info"
  MAX_CONNECTIONS: "100"

  # Multi-line config file
  app.properties: |
    server.port=8080
    spring.profiles.active=production
    logging.level.root=INFO

Using ConfigMaps in Pods:

apiVersion: v1
kind: Pod
metadata:
  name: app-with-config
spec:
  containers:
    - name: app
      image: my-app:latest

      # Option 1: As environment variables
      envFrom:
        - configMapRef:
            name: app-config

      # Option 2: Specific keys as env vars
      env:
        - name: DATABASE_HOST
          valueFrom:
            configMapKeyRef:
              name: app-config
              key: APP_ENV

      # Option 3: Mount as files
      volumeMounts:
        - name: config-volume
          mountPath: /etc/config
          readOnly: true

  volumes:
    - name: config-volume
      configMap:
        name: app-config

Secrets

Secrets are like ConfigMaps but for sensitive data — passwords, API keys, TLS certificates. Values are base64-encoded (not encrypted by default).

Creating Secrets:

# From literal values
kubectl create secret generic db-credentials \
  --from-literal=DB_USER=admin \
  --from-literal=DB_PASSWORD=s3cur3p@ss

# From files (e.g., TLS certificates)
kubectl create secret tls my-tls-secret \
  --cert=tls.crt \
  --key=tls.key

# View the secret (values are base64 encoded)
kubectl get secret db-credentials -o yaml

Declarative YAML:

apiVersion: v1
kind: Secret
metadata:
  name: db-credentials
type: Opaque
data:
  # Values must be base64 encoded
  DB_USER: YWRtaW4=              # echo -n "admin" | base64
  DB_PASSWORD: czNjdXIzcEBzcw==  # echo -n "s3cur3p@ss" | base64
---
# Or use stringData for plain text (Kubernetes encodes it for you)
apiVersion: v1
kind: Secret
metadata:
  name: api-keys
type: Opaque
stringData:
  API_KEY: "my-super-secret-api-key"
  JWT_SECRET: "jwt-signing-secret-256-bit"

Using Secrets in Pods:

apiVersion: v1
kind: Pod
metadata:
  name: app-with-secrets
spec:
  containers:
    - name: app
      image: my-app:latest

      # As environment variables
      env:
        - name: DB_USER
          valueFrom:
            secretKeyRef:
              name: db-credentials
              key: DB_USER
        - name: DB_PASSWORD
          valueFrom:
            secretKeyRef:
              name: db-credentials
              key: DB_PASSWORD

      # Mount as files
      volumeMounts:
        - name: secret-volume
          mountPath: /etc/secrets
          readOnly: true

  volumes:
    - name: secret-volume
      secret:
        secretName: db-credentials

Important: Kubernetes Secrets are base64-encoded, not encrypted. For production, consider:

Enabling encryption at rest for etcd

Using external secret managers (Vault, AWS Secrets Manager, Azure Key Vault)

Using the External Secrets Operator to sync from external stores

Part 8: Namespaces

Namespaces are virtual clusters within a physical cluster. They provide isolation, organization, and resource management.

Default Namespaces

Every Kubernetes cluster starts with these namespaces:

kubectl get namespaces

NAME              STATUS   AGE
default           Active   1d    # Where your resources go if you don't specify
kube-system       Active   1d    # Kubernetes system components (API server, DNS, etc.)
kube-public       Active   1d    # Publicly accessible data (rarely used)
kube-node-lease   Active   1d    # Node heartbeat leases

Creating and Using Namespaces

apiVersion: v1
kind: Namespace
metadata:
  name: staging
  labels:
    environment: staging
---
apiVersion: v1
kind: Namespace
metadata:
  name: production
  labels:
    environment: production

# Create namespace
kubectl apply -f namespaces.yaml

# Create resources in a specific namespace
kubectl apply -f deployment.yaml -n staging

# List resources in a namespace
kubectl get pods -n staging
kubectl get all -n production

# List resources across all namespaces
kubectl get pods --all-namespaces
kubectl get pods -A    # Short form

Setting Default Namespace

Tired of typing -n staging every time?

# Set default namespace for current context
kubectl config set-context --current --namespace=staging

# Now all commands target 'staging' by default
kubectl get pods    # Shows pods in 'staging'

Resource Quotas

Control how much resources a namespace can consume:

apiVersion: v1
kind: ResourceQuota
metadata:
  name: staging-quota
  namespace: staging
spec:
  hard:
    pods: "20"
    requests.cpu: "4"
    requests.memory: "8Gi"
    limits.cpu: "8"
    limits.memory: "16Gi"
    services: "10"
    persistentvolumeclaims: "5"

Cross-Namespace Communication

Services in different namespaces can communicate using the full DNS name:

<service-name>.<namespace>.svc.cluster.local

# Pod in 'staging' namespace accessing a service in 'production' namespace
env:
  - name: API_URL
    value: "http://api-service.production.svc.cluster.local:80"

Part 9: Labels and Selectors

Labels are key-value pairs attached to Kubernetes objects. They're how Kubernetes organizes and selects resources.

Adding Labels

apiVersion: v1
kind: Pod
metadata:
  name: api-server
  labels:
    app: api
    environment: production
    team: backend
    version: v2.1.0

# Add a label to an existing resource
kubectl label pod api-server tier=backend

# Remove a label
kubectl label pod api-server tier-

# Update a label
kubectl label pod api-server version=v2.2.0 --overwrite

Using Selectors

Selectors filter resources by labels:

# Equality-based selectors
kubectl get pods -l app=api
kubectl get pods -l environment=production
kubectl get pods -l 'environment!=staging'

# Set-based selectors
kubectl get pods -l 'environment in (production, staging)'
kubectl get pods -l 'team notin (frontend)'
kubectl get pods -l 'app, environment'    # Has both labels (any value)

# Combine selectors
kubectl get pods -l 'app=api,environment=production'

Labels vs Annotations

Feature	Labels	Annotations
Purpose	Identify and select resources	Attach non-identifying metadata
Used by selectors	Yes	No
Size limit	63 chars (value)	256KB
Examples	`app=web`, `env=prod`	`description`, `git-commit`, `config-hash`

metadata:
  labels:
    app: api                     # Used for selection
    environment: production      # Used for selection
  annotations:
    description: "Main API server"           # Not used for selection
    git-commit: "abc123def456"               # Build metadata
    kubectl.kubernetes.io/last-applied-configuration: "..."  # System annotation

Label Best Practices

Follow the recommended labeling convention:

metadata:
  labels:
    # Recommended labels (kubernetes.io convention)
    app.kubernetes.io/name: my-app
    app.kubernetes.io/instance: my-app-prod
    app.kubernetes.io/version: "2.1.0"
    app.kubernetes.io/component: backend
    app.kubernetes.io/part-of: ecommerce
    app.kubernetes.io/managed-by: helm

    # Custom labels for your organization
    team: platform
    cost-center: engineering

Part 10: Putting It All Together

Let's deploy a complete application: a Node.js API with a PostgreSQL database.

Project Structure

k8s/
├── namespace.yaml
├── configmap.yaml
├── secret.yaml
├── postgres-deployment.yaml
├── postgres-service.yaml
├── api-deployment.yaml
└── api-service.yaml

Step 1: Namespace

# k8s/namespace.yaml
apiVersion: v1
kind: Namespace
metadata:
  name: demo-app
  labels:
    app: demo

Step 2: ConfigMap and Secret

# k8s/configmap.yaml
apiVersion: v1
kind: ConfigMap
metadata:
  name: api-config
  namespace: demo-app
data:
  NODE_ENV: "production"
  PORT: "3000"
  DB_HOST: "postgres-service"
  DB_PORT: "5432"
  DB_NAME: "myapp"

# k8s/secret.yaml
apiVersion: v1
kind: Secret
metadata:
  name: db-credentials
  namespace: demo-app
type: Opaque
stringData:
  DB_USER: "appuser"
  DB_PASSWORD: "supersecretpassword"
  POSTGRES_PASSWORD: "supersecretpassword"

Step 3: PostgreSQL

# k8s/postgres-deployment.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
  name: postgres
  namespace: demo-app
  labels:
    app: postgres
spec:
  replicas: 1
  selector:
    matchLabels:
      app: postgres
  template:
    metadata:
      labels:
        app: postgres
    spec:
      containers:
        - name: postgres
          image: postgres:16-alpine
          ports:
            - containerPort: 5432
          env:
            - name: POSTGRES_DB
              valueFrom:
                configMapKeyRef:
                  name: api-config
                  key: DB_NAME
            - name: POSTGRES_USER
              valueFrom:
                secretKeyRef:
                  name: db-credentials
                  key: DB_USER
            - name: POSTGRES_PASSWORD
              valueFrom:
                secretKeyRef:
                  name: db-credentials
                  key: POSTGRES_PASSWORD
          volumeMounts:
            - name: postgres-data
              mountPath: /var/lib/postgresql/data
          resources:
            requests:
              memory: "256Mi"
              cpu: "250m"
            limits:
              memory: "512Mi"
              cpu: "500m"
          readinessProbe:
            exec:
              command: ["pg_isready", "-U", "appuser"]
            initialDelaySeconds: 5
            periodSeconds: 10
      volumes:
        - name: postgres-data
          emptyDir: {}    # Use PersistentVolume in production!

# k8s/postgres-service.yaml
apiVersion: v1
kind: Service
metadata:
  name: postgres-service
  namespace: demo-app
spec:
  type: ClusterIP
  selector:
    app: postgres
  ports:
    - port: 5432
      targetPort: 5432

Step 4: Node.js API

# k8s/api-deployment.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
  name: api
  namespace: demo-app
  labels:
    app: api
spec:
  replicas: 3
  selector:
    matchLabels:
      app: api
  strategy:
    type: RollingUpdate
    rollingUpdate:
      maxSurge: 1
      maxUnavailable: 0
  template:
    metadata:
      labels:
        app: api
    spec:
      initContainers:
        - name: wait-for-db
          image: busybox
          command: ["sh", "-c", "until nc -z postgres-service 5432; do echo waiting for postgres; sleep 2; done"]
      containers:
        - name: api
          image: node:20-alpine
          command: ["node", "server.js"]
          ports:
            - containerPort: 3000
          envFrom:
            - configMapRef:
                name: api-config
          env:
            - name: DB_USER
              valueFrom:
                secretKeyRef:
                  name: db-credentials
                  key: DB_USER
            - name: DB_PASSWORD
              valueFrom:
                secretKeyRef:
                  name: db-credentials
                  key: DB_PASSWORD
          resources:
            requests:
              memory: "128Mi"
              cpu: "100m"
            limits:
              memory: "256Mi"
              cpu: "500m"
          readinessProbe:
            httpGet:
              path: /health
              port: 3000
            initialDelaySeconds: 10
            periodSeconds: 5
          livenessProbe:
            httpGet:
              path: /health
              port: 3000
            initialDelaySeconds: 30
            periodSeconds: 15

# k8s/api-service.yaml
apiVersion: v1
kind: Service
metadata:
  name: api-service
  namespace: demo-app
spec:
  type: NodePort
  selector:
    app: api
  ports:
    - port: 80
      targetPort: 3000
      nodePort: 30000

Step 5: Deploy Everything

# Apply all manifests in order
kubectl apply -f k8s/namespace.yaml
kubectl apply -f k8s/configmap.yaml
kubectl apply -f k8s/secret.yaml
kubectl apply -f k8s/postgres-deployment.yaml
kubectl apply -f k8s/postgres-service.yaml
kubectl apply -f k8s/api-deployment.yaml
kubectl apply -f k8s/api-service.yaml

# Or apply everything at once
kubectl apply -f k8s/

# Check everything is running
kubectl get all -n demo-app

Expected output:

NAME                            READY   STATUS    RESTARTS   AGE
pod/api-7d9f8b6c5-abc12        1/1     Running   0          60s
pod/api-7d9f8b6c5-def34        1/1     Running   0          60s
pod/api-7d9f8b6c5-ghi56        1/1     Running   0          60s
pod/postgres-5c8f9d7b2-xyz89   1/1     Running   0          65s

NAME                       TYPE        CLUSTER-IP      EXTERNAL-IP   PORT(S)
service/api-service        NodePort    10.96.100.50    <none>        80:30000/TCP
service/postgres-service   ClusterIP   10.96.100.51    <none>        5432/TCP

NAME                       READY   UP-TO-DATE   AVAILABLE   AGE
deployment.apps/api        3/3     3            3           60s
deployment.apps/postgres   1/1     1            1           65s

# Access the API (minikube)
minikube service api-service -n demo-app --url

# Test it
curl http://<minikube-ip>:30000/health

Cleanup

# Delete all resources in the namespace
kubectl delete namespace demo-app

# Or delete specific resources
kubectl delete -f k8s/

Exercises

Exercise 1: Deploy a Web Application

Deploy an nginx web server with:

3 replicas
A ConfigMap with a custom index.html
A NodePort Service on port 30080
Liveness and readiness probes

Exercise 2: Rolling Update Practice

Deploy nginx:1.24 with 3 replicas
Update to nginx:1.25 and watch the rolling update
Check rollout history
Roll back to 1.24
Verify the rollback succeeded

Exercise 3: Multi-Service Application

Deploy a complete stack in a my-project namespace:

A Redis deployment (1 replica) with a ClusterIP Service
A Python/Node.js API (3 replicas) that connects to Redis
Use ConfigMaps for Redis connection settings
Use Secrets for any authentication
An init container that waits for Redis to be ready

What's Next?

In the next post, we'll dive into Dockerfile Best Practices & Multi-Stage Builds — mastering advanced techniques to build production-ready container images:

Image size optimization (alpine, slim, distroless, scratch)
Layer caching strategies
Multi-stage builds for any language
Security hardening (non-root, read-only filesystem)
BuildKit features (cache mounts, secrets, multi-platform)

Summary and Key Takeaways

✅ Kubernetes orchestrates containers at scale with self-healing, scaling, and rolling updates
✅ The control plane (API server, etcd, scheduler) manages cluster state; worker nodes run Pods
✅ Pods are the smallest deployable unit — use Deployments to manage them, never create Pods directly
✅ Deployments provide rolling updates, rollbacks, and scaling with zero downtime
✅ Services give Pods a stable network endpoint — use ClusterIP for internal, NodePort/LoadBalancer for external
✅ ConfigMaps store configuration; Secrets store sensitive data (base64-encoded, not encrypted)
✅ Namespaces isolate resources and enable resource quotas per team or environment
✅ Labels and selectors are how Kubernetes organizes and connects resources
✅ Always set resource requests/limits and health checks (liveness, readiness, startup probes)
✅ Use kubectl describe and kubectl logs as your primary debugging tools

Series: Docker & Kubernetes Learning Roadmap
Previous: Phase 2: Docker Compose & Multi-Container Apps
Next: Deep Dive: Dockerfile Best Practices & Multi-Stage Builds

Have questions about Kubernetes? Feel free to reach out or leave a comment!

What You'll Learn

Part 1: What is Kubernetes?

Why Kubernetes?

Kubernetes vs Docker Compose vs Docker Swarm

Kubernetes Distributions

Part 2: Kubernetes Architecture

Control Plane Components

Worker Node Components

How It All Fits Together

Part 3: Setting Up Kubernetes

Installing minikube

Starting Your Cluster

Installing kubectl

kubectl Essentials

Part 4: Pods

Why Pods, Not Containers?

Creating Your First Pod

Pod Lifecycle

Multi-Container Pods

Init Containers

Debugging Pods

Part 5: Deployments

Why Deployments?

Creating a Deployment

Scaling

Rolling Updates

Rollbacks

Health Checks (Probes)

Part 6: Services

How Services Work

Service Types

1. ClusterIP (default)

2. NodePort

3. LoadBalancer

4. ExternalName

Service Discovery

Part 7: ConfigMaps and Secrets

ConfigMaps

Secrets

Part 8: Namespaces

Default Namespaces

Creating and Using Namespaces

Setting Default Namespace

Resource Quotas

Cross-Namespace Communication

Part 9: Labels and Selectors

Adding Labels

Using Selectors

Labels vs Annotations

Label Best Practices

Part 10: Putting It All Together

Project Structure

Step 1: Namespace

Step 2: ConfigMap and Secret

Step 3: PostgreSQL

Step 4: Node.js API

Step 5: Deploy Everything

Cleanup

Exercises

Exercise 1: Deploy a Web Application

Exercise 2: Rolling Update Practice

Exercise 3: Multi-Service Application

What's Next?

Summary and Key Takeaways

📬 Subscribe to Newsletter

💬 Comments
