Docker Networking & Volumes Deep Dive

You've learned to build and run containers — now let's understand how they talk to each other and how they persist data. Networking and storage are two areas where developers often run into unexpected behavior, and understanding them deeply will save you hours of debugging.

This post covers everything you need to know about Docker networking and storage for production use.

Time commitment: 3–4 days, 1–2 hours daily
Prerequisites: Phase 1: Docker Fundamentals, Phase 2: Docker Compose & Multi-Container Apps

Part 1: Docker Networking

How Docker Networking Works

When Docker starts, it creates a virtual network interface on your host machine. Every container gets its own network namespace — an isolated view of the network stack. Containers can communicate through Docker-managed networks.

# See all networks on your system
docker network ls

# Output
NETWORK ID     NAME      DRIVER    SCOPE
a1b2c3d4e5f6   bridge    bridge    local
b2c3d4e5f6a1   host      host      local
c3d4e5f6a1b2   none      null      local

Docker ships with three built-in networks and lets you create custom ones.

Network Drivers

Bridge Network (Default)

The bridge driver is the default for standalone containers. Docker creates a virtual Ethernet bridge (docker0) on the host, and every container connected to it gets an IP address in that subnet.

# Run a container — it joins the default bridge automatically
docker run -d --name web nginx

# Inspect the default bridge network
docker network inspect bridge

Default bridge limitations:

Containers can only communicate by IP address (no DNS)
Not recommended for production — use custom bridge networks

Custom bridge networks solve this:

# Create a custom network
docker network create myapp-network

# Run containers on it
docker run -d --name backend --network myapp-network myapp:latest
docker run -d --name db --network myapp-network postgres:16

# backend can now reach db by hostname
docker exec backend ping db   # ✅ Works via DNS

Custom bridge networks give you:

Automatic DNS resolution by container name
Better isolation from other containers
Can connect/disconnect containers at runtime

Host Network

The container shares the host's network stack directly — no network namespace isolation.

docker run --network host nginx
# nginx now listens on host port 80 directly (no -p needed)

When to use host networking:

Maximum network performance (no NAT overhead)
Tools that need access to host network interfaces (monitoring agents, packet sniffers)
Linux only — doesn't work on Docker Desktop for Mac/Windows

Security consideration: The container sees all host network interfaces. Use with caution.

None Network

Completely disables networking for the container.

docker run --network none alpine sh
# No network interfaces except loopback

Useful for batch jobs that process local files and don't need network access.

Overlay Network

Overlay networks span multiple Docker hosts (used with Docker Swarm or Kubernetes). They allow containers on different machines to communicate as if they're on the same network.

# Only available in Swarm mode
docker network create --driver overlay my-overlay

For single-host development, you won't need overlay networks — that's Kubernetes territory.

Container DNS and Service Discovery

Docker runs an embedded DNS server at 127.0.0.11 for custom networks. When a container does a DNS lookup for another container name, Docker resolves it to that container's IP.

# Create network and containers
docker network create backend-net
docker run -d --name postgres --network backend-net postgres:16
docker run -d --name redis --network backend-net redis:7
docker run -d --name api --network backend-net myapi:latest

# api can reach postgres and redis by name
# postgres://postgres:5432  ✅
# redis://redis:6379         ✅

DNS aliases — give a container multiple hostnames:

docker run -d \
  --network backend-net \
  --network-alias db \
  --network-alias database \
  --name postgres \
  postgres:16

# Now reachable as "postgres", "db", OR "database"

Service discovery in Docker Compose is automatic — every service name becomes a DNS hostname:

services:
  api:
    build: .
    # Can reach "db" and "cache" by name
  db:
    image: postgres:16
  cache:
    image: redis:7

Port Publishing

Containers are isolated by default — you must explicitly publish ports to make them accessible from the host.

# -p host_port:container_port
docker run -p 8080:80 nginx          # host:8080 → container:80
docker run -p 127.0.0.1:8080:80 nginx  # bind to localhost only (safer)
docker run -p 80 nginx               # random host port → container:80

# Check which port was assigned
docker port <container_id>

Best practice: Bind to 127.0.0.1 in development so the port isn't exposed to the local network:

docker run -p 127.0.0.1:5432:5432 postgres:16
# Only accessible from localhost, not other machines on your network

Network Security and Isolation

Separate networks per concern

# docker-compose.yml — production-style network isolation
services:
  nginx:
    image: nginx:alpine
    networks:
      - frontend
      - backend

  api:
    build: .
    networks:
      - backend
      - data

  db:
    image: postgres:16
    networks:
      - data   # db is NOT on frontend — nginx can't reach it directly

networks:
  frontend:
  backend:
  data:

This architecture means:

nginx talks to api (both on backend)
api talks to db (both on data)
nginx cannot directly reach db — must go through api

Internal networks (no external access)

docker network create --internal secure-net
# Containers on this network can't reach the internet

Useful for databases and internal services that should never have outbound internet access.

Useful Network Commands

# List networks
docker network ls

# Inspect a network (shows connected containers and their IPs)
docker network inspect myapp-network

# Create a network
docker network create --driver bridge --subnet 172.20.0.0/16 myapp-network

# Connect a running container to a network
docker network connect myapp-network my-container

# Disconnect
docker network disconnect myapp-network my-container

# Remove unused networks
docker network prune

# Show container's network settings
docker inspect --format='{{json .NetworkSettings}}' my-container | jq

Part 2: Docker Storage

The Container Filesystem Problem

Containers have a writable layer on top of their image layers. By default, everything written inside a container is stored in this writable layer:

┌─────────────────────────────┐
│   Writable Container Layer  │  ← deleted when container is removed
├─────────────────────────────┤
│     Image Layer 3 (RO)      │
├─────────────────────────────┤
│     Image Layer 2 (RO)      │
├─────────────────────────────┤
│     Image Layer 1 (RO)      │
└─────────────────────────────┘

Problems with the writable layer:

Data is lost when the container is removed
Data can't be shared between containers
Writing uses a copy-on-write storage driver — slower than native filesystem I/O

Docker offers three solutions: volumes, bind mounts, and tmpfs.

Volumes

Volumes are the preferred mechanism for persisting data. Docker manages them completely — they live in /var/lib/docker/volumes/ on Linux and are independent of the container lifecycle.

# Create a named volume
docker volume create mydata

# Use it when running a container
docker run -d \
  --name postgres \
  -v mydata:/var/lib/postgresql/data \
  postgres:16

# The data in /var/lib/postgresql/data persists even after the container is removed

Volume in Docker Compose:

services:
  db:
    image: postgres:16
    volumes:
      - pgdata:/var/lib/postgresql/data
    environment:
      POSTGRES_PASSWORD: secret

volumes:
  pgdata:   # Docker manages this volume

Volume commands

# List volumes
docker volume ls

# Inspect a volume (shows mountpoint on host)
docker volume inspect mydata

# Remove a volume
docker volume rm mydata

# Remove all unused volumes
docker volume prune

# Create with options
docker volume create \
  --driver local \
  --opt type=nfs \
  --opt o=addr=192.168.1.100,rw \
  --opt device=:/path/to/dir \
  nfs-volume

# First container writes data
docker run -d --name writer -v shared-data:/data alpine \
  sh -c "echo 'hello' > /data/message.txt && sleep 3600"

# Second container reads from the same volume
docker run --rm -v shared-data:/data alpine cat /data/message.txt
# Output: hello

Bind Mounts

Bind mounts map a host filesystem path directly into the container. Unlike volumes, you control exactly where the data lives on the host.

# Mount current directory into container
docker run -v $(pwd):/app node:20 npm test

# Mount a specific host path
docker run -v /host/path:/container/path nginx

Bind mount in Docker Compose (typical dev setup):

services:
  api:
    build: .
    volumes:
      - ./src:/app/src          # source code — live reload
      - ./config:/app/config    # config files
      - /app/node_modules       # anonymous volume — don't overwrite node_modules

The anonymous volume trick (/app/node_modules) prevents the host's node_modules from overwriting the container's installed packages.

Bind mount options

# Read-only mount — container can't modify the files
docker run -v $(pwd)/config:/app/config:ro myapp

# Consistent, cached, delegated (macOS performance hints — legacy)
docker run -v $(pwd):/app:cached myapp

Volumes vs Bind Mounts — when to use each

	Volumes	Bind Mounts
Managed by	Docker	You (host path)
Best for	Persistent data (databases)	Development (live code reload)
Portable	✅ Yes	❌ Depends on host path
Performance	✅ Better on Linux	✅ Great for read-heavy
Backup	Via `docker volume` commands	Direct filesystem access
Production	✅ Preferred	⚠️ Use carefully

tmpfs Mounts

tmpfs mounts store data in the host's memory — never written to disk. Perfect for sensitive data (tokens, passwords) that shouldn't persist.

docker run -d \
  --tmpfs /tmp \
  --tmpfs /run:rw,noexec,nosuid,size=100m \
  nginx

In Docker Compose:

services:
  api:
    image: myapi
    tmpfs:
      - /tmp
      - /run

Use cases:

Temporary session data
Sensitive credentials that must never hit disk
High-speed scratch space for processing

Storage Drivers

Docker uses a union filesystem (storage driver) to layer images. The driver affects I/O performance and is mostly transparent to you, but worth understanding.

Driver	OS	Notes
`overlay2`	Linux	Default, recommended
`aufs`	Ubuntu (legacy)	Older, being phased out
`devicemapper`	RHEL/CentOS (legacy)	Avoid unless required
`vfs`	Any	Slow, used for testing

# Check your storage driver
docker info | grep "Storage Driver"
# Storage Driver: overlay2

The storage driver only affects the writable container layer — volumes bypass it entirely and use native filesystem I/O.

Production Storage Patterns

Pattern 1: Database with named volume

services:
  postgres:
    image: postgres:16-alpine
    environment:
      POSTGRES_DB: myapp
      POSTGRES_USER: app
      POSTGRES_PASSWORD_FILE: /run/secrets/db_password
    volumes:
      - pgdata:/var/lib/postgresql/data
      - ./init.sql:/docker-entrypoint-initdb.d/init.sql:ro
    secrets:
      - db_password

volumes:
  pgdata:

secrets:
  db_password:
    file: ./secrets/db_password.txt

Pattern 2: Application with separate code and data volumes

services:
  app:
    image: myapp:${VERSION}
    volumes:
      - uploads:/app/uploads      # user-uploaded files persist
      - logs:/app/logs            # logs persist for debugging
    tmpfs:
      - /tmp                      # temp files in memory

volumes:
  uploads:
  logs:

Pattern 3: Volume backup and restore

# Backup: create a tar from the volume
docker run --rm \
  -v pgdata:/data \
  -v $(pwd):/backup \
  alpine tar czf /backup/pgdata-backup.tar.gz -C /data .

# Restore: extract tar into volume
docker run --rm \
  -v pgdata:/data \
  -v $(pwd):/backup \
  alpine tar xzf /backup/pgdata-backup.tar.gz -C /data

Pattern 4: NFS volume for shared storage across hosts

docker volume create \
  --driver local \
  --opt type=nfs4 \
  --opt o=addr=nfs-server.example.com,rw \
  --opt device=:/exports/mydata \
  nfs-shared

Common Storage Mistakes

Mistake 1: Writing database data to the container writable layer

# ❌ BAD — data lost when container is removed
docker run -d postgres:16

# ✅ GOOD — data persists
docker run -d -v pgdata:/var/lib/postgresql/data postgres:16

Mistake 2: Using bind mounts for production databases

# ❌ BAD — depends on specific host path, permissions issues
volumes:
  - /home/ubuntu/postgres-data:/var/lib/postgresql/data

# ✅ GOOD — Docker manages it
volumes:
  - pgdata:/var/lib/postgresql/data

Mistake 3: Forgetting to exclude node_modules from bind mounts

# ❌ BAD — host's node_modules overwrites container's
volumes:
  - .:/app

# ✅ GOOD — anonymous volume shadows node_modules
volumes:
  - .:/app
  - /app/node_modules

Mistake 4: Not setting volume permissions

# In Dockerfile — create directory and set ownership before declaring VOLUME
RUN mkdir -p /app/data && chown -R node:node /app/data
USER node
VOLUME /app/data

Complete Example: Full-Stack App with Networking and Storage

# docker-compose.yml
services:
  nginx:
    image: nginx:alpine
    ports:
      - "80:80"
      - "443:443"
    volumes:
      - ./nginx.conf:/etc/nginx/nginx.conf:ro
      - ssl-certs:/etc/nginx/certs:ro
    networks:
      - frontend
    depends_on:
      - api

  api:
    build:
      context: .
      dockerfile: Dockerfile
      target: production
    environment:
      DATABASE_URL: postgresql://app:${DB_PASSWORD}@db:5432/myapp
      REDIS_URL: redis://cache:6379
    volumes:
      - uploads:/app/uploads
    tmpfs:
      - /tmp
    networks:
      - frontend
      - backend
    depends_on:
      db:
        condition: service_healthy
      cache:
        condition: service_healthy

  db:
    image: postgres:16-alpine
    environment:
      POSTGRES_DB: myapp
      POSTGRES_USER: app
      POSTGRES_PASSWORD: ${DB_PASSWORD}
    volumes:
      - pgdata:/var/lib/postgresql/data
    networks:
      - backend
    healthcheck:
      test: ["CMD-SHELL", "pg_isready -U app -d myapp"]
      interval: 10s
      timeout: 5s
      retries: 5

  cache:
    image: redis:7-alpine
    command: redis-server --appendonly yes --requirepass ${REDIS_PASSWORD}
    volumes:
      - redisdata:/data
    networks:
      - backend
    healthcheck:
      test: ["CMD", "redis-cli", "--pass", "${REDIS_PASSWORD}", "ping"]
      interval: 10s
      timeout: 5s
      retries: 5

networks:
  frontend:    # nginx ↔ api
  backend:     # api ↔ db ↔ cache (nginx can NOT reach db or cache directly)

volumes:
  pgdata:      # postgres data
  redisdata:   # redis persistence
  uploads:     # user uploads
  ssl-certs:   # TLS certificates

This setup:

nginx can only talk to api (not db or cache directly)
api can talk to db and cache by name via DNS
All data volumes persist across container restarts
Healthchecks ensure dependent services are ready before api starts

Debugging Networking Issues

# Is the container on the right network?
docker inspect --format='{{json .NetworkSettings.Networks}}' my-container | jq

# Can container A reach container B?
docker exec container-a ping container-b
docker exec container-a curl http://container-b:8080/health

# What ports is a container listening on?
docker port my-container

# See real-time network traffic (requires tcpdump in container)
docker exec -it my-container sh -c "apk add tcpdump && tcpdump -i eth0"

# DNS resolution from inside container
docker exec my-container nslookup db
docker exec my-container cat /etc/resolv.conf

Debugging Storage Issues

# What volumes does a container have?
docker inspect --format='{{json .Mounts}}' my-container | jq

# What's in a volume?
docker run --rm -v my-volume:/data alpine ls -la /data

# Volume disk usage
docker system df -v

# Check permissions inside container
docker exec my-container ls -la /app/uploads

# Copy files to/from container
docker cp my-container:/app/logs/error.log ./error.log
docker cp ./seed.sql my-container:/tmp/seed.sql

Summary and Key Takeaways

✅ Custom bridge networks provide automatic DNS — containers find each other by name, not IP
✅ Use separate networks per tier (frontend/backend/data) to isolate services from each other
✅ Publish ports with 127.0.0.1: prefix in development to avoid exposing to the local network
✅ Volumes are Docker-managed, portable, and preferred for production data persistence
✅ Bind mounts are great for development (live code reload) — avoid for production databases
✅ Use tmpfs for sensitive in-memory data that must never be written to disk
✅ Always declare named volumes for stateful services (postgres, redis, elasticsearch)
✅ The anonymous volume trick (- /app/node_modules) prevents bind mounts from clobbering container dependencies
✅ Use docker network inspect and docker exec ... ping for network debugging
✅ Volumes bypass the storage driver — they use native filesystem I/O and are faster than the writable layer

Series: Docker & Kubernetes Learning Roadmap
Previous: Deep Dive: Dockerfile Best Practices & Multi-Stage Builds
Next: Deep Dive: Kubernetes Workloads (Coming Soon)

Have questions about Docker networking or storage? Feel free to reach out or leave a comment!

Docker Networking & Volumes Deep Dive

Part 1: Docker Networking

How Docker Networking Works

Network Drivers

Bridge Network (Default)

Host Network

None Network

Overlay Network

Container DNS and Service Discovery

Port Publishing

Network Security and Isolation

Separate networks per concern

Internal networks (no external access)

Useful Network Commands

Part 2: Docker Storage

The Container Filesystem Problem

Volumes

Volume commands

Bind Mounts

Bind mount options

Volumes vs Bind Mounts — when to use each

tmpfs Mounts

Storage Drivers

Production Storage Patterns

Pattern 1: Database with named volume

Pattern 2: Application with separate code and data volumes

Pattern 3: Volume backup and restore

Pattern 4: NFS volume for shared storage across hosts

Common Storage Mistakes

Complete Example: Full-Stack App with Networking and Storage

Debugging Networking Issues

Debugging Storage Issues

Summary and Key Takeaways

📬 Subscribe to Newsletter

💬 Comments

Part 1: Docker Networking

How Docker Networking Works

Network Drivers

Bridge Network (Default)

Host Network

None Network

Overlay Network

Container DNS and Service Discovery

Port Publishing

Network Security and Isolation

Separate networks per concern

Internal networks (no external access)

Useful Network Commands

Part 2: Docker Storage

The Container Filesystem Problem

Volumes

Volume commands

Sharing volumes between containers

Bind Mounts

Bind mount options

Volumes vs Bind Mounts — when to use each

tmpfs Mounts

Storage Drivers

Production Storage Patterns

Pattern 1: Database with named volume

Pattern 2: Application with separate code and data volumes

Pattern 3: Volume backup and restore

Pattern 4: NFS volume for shared storage across hosts

Common Storage Mistakes

Complete Example: Full-Stack App with Networking and Storage

Debugging Networking Issues

Debugging Storage Issues

Summary and Key Takeaways

📬 Subscribe to Newsletter

💬 Comments
